- Multilevel security & manageability with up to Intel vPro® Enterprise
- Removable dust shield to assist with upkeep & extend the lifecycle of the system
- Highly configurable compact PC with customizable expansion slots
- Ideal for healthcare, retail, & finance with support for up to 4 monitors
| Processor |
|---|
| Processor generation |
Intel® Core™ i7 (14th gen) |
| Memory bandwidth supported by processor (max) |
89.6 GB/s |
| Processor cache type |
Smart Cache |
| Processor cache |
33 MB |
| Processor model |
i7-14700T |
| Processor manufacturer |
Intel |
| Processor boost frequency |
5.2 GHz |
| Processor socket |
LGA 1700 |
| Processor threads |
28 |
| Processor cores |
20 |
| Processor family |
Intel® Core™ i7 |
| Performance cores |
8 |
| Efficient cores |
12 |
| Performance-core base frequency |
1.3 GHz |
| Efficient-core base frequency |
0.9 GHz |
| Processor base power |
35 W |
| Maximum turbo power |
106 W |
| Efficient-core Max Turbo Frequency |
3.7 GHz |
| Performance-core Max Turbo Frequency |
5 GHz |
| Memory |
|---|
| Memory layout (slots x size) |
1 x 16 GB |
| Internal memory |
16 GB |
| Maximum internal memory |
64 GB |
| Memory slots |
2x SO-DIMM |
| Internal memory type |
DDR5-SDRAM |
| Memory clock speed |
5600 MHz |
| Memory channels |
Dual-channel |
| Storage |
|---|
| Storage media |
SSD |
| Optical drive type |
No |
| SSD interface |
PCI Express 4.0 |
| SSD capacity |
512 GB |
| Number of SSDs installed |
1 |
| Card reader integrated |
No |
| Total storage capacity |
512 GB |
| SSD form factor |
M.2 |
| Total SSDs capacity |
512 GB |
| NVMe |
Yes |
| M.2 SSD size |
2280 (22 x 80 mm) |
| Self-Encrypting Drive (SED) |
Yes |
| Graphics |
|---|
| Discrete graphics card |
No |
| On-board graphics card family |
Intel® UHD Graphics |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Intel UHD Graphics 770 |
| Graphics card |
UHD Graphics |
| On-board GPU manufacturer |
Intel |
| Performance |
|---|
| Product type |
Mini PC |
| Trusted Platform Module (TPM) |
Yes |
| Motherboard chipset |
Intel Q670 |
| Trusted Platform Module (TPM) version |
2.0 |
| Fingerprint reader |
No |
| Audio chip |
Realtek ALC233 |
| Number of speakers |
1 |
| Audio system |
High Definition Audio |
| Optical drive |
|---|
| Optical drive type |
No |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Bluetooth |
Yes |
| Bluetooth version |
5.3 |
| Wi-Fi standards |
Wi-Fi 7 (802.11be) |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Ethernet interface type |
Gigabit Ethernet |
| WLAN controller model |
Intel Wi-Fi 7 BE200 |
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| Antenna type |
2x2 |
| WLAN controller manufacturer |
Intel |
| Ports & interfaces |
|---|
| Combo headphone/mic port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| Thunderbolt 3 ports quantity |
0 |
| HDMI version |
2.1 |
| USB 2.0 ports quantity |
0 |
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| DisplayPorts quantity |
2 |
| USB 3.2 Gen 2x2 Type-C ports quantity |
1 |
| Power |
|---|
| Power supply |
135 W |
| Technical details |
|---|
| Cable lock slot type |
Kensington |
| Product type |
Mini PC |
| Trusted Platform Module (TPM) |
Yes |
| Product colour |
Black |
| Chassis type |
Mini PC |
| Audio system |
High Definition Audio |
| Cable lock slot |
Yes |
| Motherboard chipset |
Intel Q670 |
| Design |
|---|
| Volume |
1 L |
| Cable lock slot type |
Kensington |
| Product colour |
Black |
| Chassis type |
Mini PC |
| Cable lock slot |
Yes |
| Software |
|---|
| Operating system language |
English |
| Operating system installed |
Windows 11 Pro |
| Display |
|---|
| Display included |
No |
| Processor special features |
|---|
| Intel® Smart Cache |
Yes |
| Audio |
|---|
| Audio chip |
Realtek ALC233 |
| Number of speakers |
1 |
| Audio system |
High Definition Audio |
| Weight & dimensions |
|---|
| Volume |
1 L |
| Width |
179 mm |
| Depth |
182.9 mm |
| Height |
36.5 mm |
| Weight |
1.25 kg |
| Packaging content |
|---|
| Mouse included |
Yes |
| Keyboard included |
Yes |
| Mouse connectivity |
Wired |
| Display included |
No |
| Keyboard connectivity |
Wired |
| Certificates |
|---|
| Certification |
TCO,RoHS,ErP |
| Keyboard |
|---|
| Keyboard connectivity |
Wired |
| Other features |
|---|
| Number of speakers |
1 |
| Trusted Platform Module (TPM) |
Yes |
| On-board graphics card |
Yes |
| Processor manufacturer |
Intel |
| Graphics card |
UHD Graphics |
| Ethernet interface type |
Gigabit Ethernet |
