| Cellular network |
3GPP Release |
3GPP Release15 |
Yes |
|
| Network |
5G SA/NSA/LTE/3G |
Yes |
|
| Modulation |
Sub6G
DL: 256QAM
UL: 256QAM
LTE
DL:256QAM
UL: 64QAM |
Yes |
|
| Bandwidth |
Sub6G: 40MHz, 50MHz, 60MHz, 80MHz, 90MHz,100MHz |
Yes |
|
| Network Slicling |
|
No |
|
| Transmitter power |
25dBm(inerfull) for n78,
23dBm for other bands |
Yes |
n78 support PC2 |
| 5G Sub6 Bands |
n1/n3/n7/n8/n20/n28/n40/n77/n78 |
Yes |
|
| 5G mmWave Bands |
|
No |
|
| 4G Bands |
B1/B2/B3/B4/B7/B8/B20/B28/B38/ |
Yes |
|
| 3G Bands |
B1/2/4/5/8 |
Yes |
|
| 2G Bands |
|
No |
|
| MIMO for wireless |
5G Sub6:n1,n3,n7,n40,n77,n78 supports 4*4MIMO；
LTE: B1,B3,B7,B38supports 4MIMO
|
Yes |
|
| Default antenna |
Internal antenna for all bands |
Yes |
|
| Antenna Gain |
700-960MHz: 0.6- 1.2dBi
1400-2700MHz: 0.3-1.9dBi
3300~4200MHz: 0.5- 1.1dbi |
Yes |
|
| Bands supported by External Antenna Ports |
|
No |
|
| Theoretical Max Rate |
5G ENDC
LTE FDD + Sub6G
DL 1.83Gb/s
UL 155Mb/s |
Yes |
LTE FDD + Sub6G
DL：LTE 4layer/256QAM + NR 100M /256QAM +75% DL duty cycle;
UL：LTE 2CA/64QAM + NR 100M/256QAM +25% UL duty cycle; |
5G SA
5G Sub6G -TDD
DL 1.43 Gb/s
UL 80Mb/s |
Yes |
DL peak rates requires: 100MHz + 256QAM + 4MIMO 75% DL duty cycle;
UL peak rates requires: 100MHz + 256QAM + 1MIMO 25% duty cycle. |
5G mmWave
DL：
UL：
|
No |
|
LTE
LTE FDD (DL Category15, UL Category13):
DL 800Mb/s
UL 75Mb/s
LTE TDD
DL 280Mb/s
UL 30Mb/s |
Yes |
FDD peak rates require DL: 256QAM + 3CA（8 layers）; UL: 64QAM + no CA
TDD peak rates require DL: 256QAM + 2CA（4 layers）; UL: 64QAM + 2CA intra-bands. And TDD frame config 2 (DL/UL ratio 7:2)
|
UMTS：
WCDMA CS: UL 64kbps/DL 64kbps
WCDMA PS: UL 384kbps/DL 384kbps
HSDPA: DL 14.4Mb/s(Category 10)
DL 21Mb/s(Category 14)
DL 42Mb/s(Category 24)
HSUPA:
UL 5.76Mb/s(Category 6)
UL 11.5Mb/s(Category 7)
|
Yes |
|
| WiFi network |
Standard |
WiFi5, 802.11b/g/n/a/ac |
Yes |
|
| Band & MIMO |
2.4G or 5G
MIMO:5GHz 2*2 2.4GHz 2*2 |
Yes |
|
| Speed |
2.4GHz MIMO 2*2 20M：>140Mbps(UDP)
5GHz MIMO 2*2 80M：>650Mbps(UDP)
|
Yes |
|
| Bandwidth |
2.4G: 20M
5G: 80M |
Yes |
|
| Modulation |
Up to 256QAM |
Yes |
|
| Default antenna |
Internal antenna for all bands |
Yes |
|
| Antenna Gain |
2.4GHz 1.37dbi；5GHz: 2.34dbi
|
Yes |
|
| Access number |
up to 10 |
Yes |
|
| Interface |
RJ45 interface |
|
No |
|
| RJ11 interface |
|
No |
|
| USB interface |
1 TypeC USB 3.0 |
Yes |
|
| External Antenna Ports |
|
No |
|
| USIM/SIM slot |
1*4FF, Standard 6PIN SIM card interface for 3V/1.8V SIM card |
Yes |
|
| Button |
Power button |
Yes |
|
| Reset button |
Yes |
|
| WiFi 2.4G/5G Switch button |
Yes |
|
| WPS button |
No |
|
| LED |
Power/Battery: White/Blue/Red |
Yes |
|
| WiFi: White/Blue |
Yes |
|
| Network: White/Blue/Red |
Yes |
|
| Singal Strength |
No |
|
| RJ45 port's LED |
No |
|
| Screen |
Type: TFT
Size: 2.44 inch
Resolution: 128*128 |
No |
|
| Battery |
4500mAh Li-ion battery, Removable |
Yes |
|
| Power consumption |
Maximum power consumption |
TBD |
Yes |
|
| Environment Specifications |
Ingress Protection |
|
No |
|
| Operating temperature |
0 to 35° C |
Yes |
|
| Storage temperature |
-20 to 45° C |
Yes |
|
| Humidity |
5% to 95%
|
Yes |
|
| Certification |
Certification |
CE, WEEE,ROHS,REACH,WiFi
|
Yes |
|
| Package contents |
AC Adapter |
|
No |
|
| USB Cable |
|
Yes |
|
| Quick Start Guide |
|
Yes |
|
| User Manuel |
|
Optional |
|
| Warranty card |
|
Optional |
|
| EAN |
|
Optional |
|
| TAC |
|
Optional |
|
| Software Feature |
Device Mode |
Automatically mode (wireless or wire auto switch) |
No |
|
| Daul WAN |
No |
|
| Hybird mode (wireless and wired are used at same time) |
No |
|
| Wireless mode |
Yes |
|
| Bridge mode |
No |
|
| Cable Broadband Mode |
No |
|
| IP networking |
IPv4/IPv6 dual stack (NDP IPv6) |
Yes |
|
| DHCP server |
Yes |
|
| VPN pass-through(L2TP/PPTP/IPSec) |
No |
|
| VPN L2TP |
No |
|
| VPN PPTP |
No |
|
| VPN IPSec |
No |
|
| VPN GRE |
No |
|
| NAT/NAPT |
Yes |
|
| Sip ALG |
No |
|
| Multiple APNs |
Optional |
|
| Firewall |
Port Forwarding |
No |
|
| Port Filtering |
No |
|
| Port Mapping |
No |
|
| Domain Filtering |
No |
|
| Upnp |
No |
|
| DMZ |
No |
|
| Remote Access/Ping switch |
No |
|
| MAC address filtering |
No |
|
| WiFi |
WiFi Switch |
Yes |
|
| Bandsteering |
No |
|
| Security mode: WPA2-PSK/WPA3-PSK, WPA2-PSK, WPA3-PSK |
Yes |
|
| WiFi Broadcast |
Yes |
|
| WiFi Isolation |
No |
|
| Auto channel selection |
Yes |
|
| WPS |
No |
|
| EasyMesh |
No |
|
| GuestSSID support |
No |
|
| WiFi Sleep Mode |
Yes |
|
| Voice |
VoNR |
No |
|
| VoLTE |
No |
|
| CSFB |
No |
|
| VoIP |
No |
|
| Device Managemnt |
Connected device Management |
Yes |
|
| SMS |
Yes |
|
| PIN/PUK management |
Yes |
|
| APN management |
Yes |
|
| Lock Frequency/Lock Cell |
Yes |
|
| TR069 with TR181 data model default |
No |
|
| Upgrade: FOTA |
Yes |
|
| ZTE Smartlife APP |
Yes |
|
| Multiple languages: Arabic, Chinese, Danish, English, Finnish, French, German, Italian, Norwegian, Portuguese, Portuguese (Brazil), Russian, Spanish, Spanish (Latin America), Swede |
Yes |
|
| Device can FOTA/TR069/remotely access on bridge mode |
No |
|
| Special Feature |
Green Mode: user can set the device to save the power |
No |
|
|
Preferred Position：Can help user to find a good position
|
No |
|
|
NFC：Andriod phone touch can access the Router WiFi
|
Yes |
support NFC Tag |
| Device Diagnosis will list all device running key status and give fix solution |
Yes |
|
| PC/Phone/PAD WebUI management self-adaptation |
Yes |
|
| OpenWrt |
No |
|
