ASUS ZenBook Pro 14 Duo OLED UX8402ZE-M3022W i9-12900H Notebook 36.8 cm (14.5") Touchscreen 2.8K Intel Core i9 32 GB LPDDR5-SDRAM 1000 GB SS
Key Features
- Model: Intel Core i9
- Operating System: Windows 11 Home
- Display Size: 15 Inch
- Display Resolution: 2880 x 1800
- Internal Storage: 1000GB
- Colour: Black
Overview
ASUS Zenbook Pro 14 Duo OLED Incredible Comes From Duo Vision Worlds first 14.5�� 2.8K 120 Hz OLED laptop with 2nd display1 Get ready to meet the seriously powerful Zenbook Pro 14 Duo OLED, an Intel Evo-certified powerhouse that lets you turn up your creative powers to the max. The flagship Intel CPU and creator-grade NVIDIA GPU are cooled for extreme performance by ASUS IceCool Plus technology, aided by the brand-new AAS Ultra mechanism, which vents the chassis and also tilts the next-generation ScreenPad Plus secondary touchscreen to a comfortable angle for a seamless and immersive visual experience. For studio-class visuals, the world-leading 2.8K OLED HDR 16:10 main touchscreen2 has a smooth 120 Hz refresh rate, PANTONE Validated color accuracy, and a cinema-grade 100% DCI-P3 gamut. Zenbook Pro 14 Duo OLED puts its rivals in the shade, making it the ultimate compact OLED laptop for the discerning creator. Worlds first 14.5�� 2.8K (2880 x 1800) 120 Hz OLED touchscreen display 16��10, 0.2 ms response time, with 93% screen-to-body ratio, 100% DCI-P3 color gamut, up to 550 nits peak brightness, support stylus 12.7�� 2.8K 120 Hz ScreenPad Plus larger NanoEdge tilting secondary touchscreen with etched anti-glare coating, 100% DCI-P3 color gamut, 500 nits brightness and stylus support Worlds first AAS Ultra technology with 2nd display enhanced air flow for supreme cooling and optimal viewing angle, with innovative AAS Ultra - ASUS Pen 2.0 support 4096 pressure levels, four interchangeable pen tips and fast USB-C charging - Intel Evo certified for the ultimate premium laptop experience - Up to 12th Gen - Intel Core i9-12900H processor for extreme performance - Up to NVIDIA GeForce RTX 3050 Ti with NVIDIA Studio drivers - Up to 2 TB PCIe 4.0 x4 SSD with 6500 MB/s transfer speed - Up to 32 GB LPDDR5 4800 MHz memory - Performance up to 85 W with ASUS IceCool Plus 12 V dual-fan boost - Dual Thunderbolt 4 provides high-speed data transfer and full-range charging - ASUS ErgoSense keyboard and touchpad for the best ergonomics - Full I/O ports latest SD Express 7.0, HDMI 2.1 - 76 Wh long-lasting high-capacity battery - 17.9 mm / 1.7 kg thin and light - Smart amplifier 350%-louder - Dolby Atmos multi-dimensional audio - Four-mic array two rear and two front mics for 360� audio capture - AI noise cancelation distraction-free calls and conferencing - Dolby Vision cinema-grade visual experience - Up to Full HD IR camera large 1.4 �m pixels for 156% more light capture - ASUS Splendid switch display modes between sRGB, Adobe RGB, 100% DCI-P3 - Adaptive RGB color sensor automatically adjusts brightness and color temperature to match ambient environment AAS ULTRA Raise the limits The tilt mechanism has been completely redesigned to create AAS Ultra, with a precision-engineered mechanism that raises the rear of ScreenPad Plus by up to 20 mm, tilting it by 12� when the laptop is opened. This positions ScreenPad Plus at the ideal viewing angle for easy cross-screen operation with the main touchscreen. It also enhances cooling by allowing 38% more airflow than the previous generation. This in turn reduces the laptop's surface temperature by up to 7�C, increasing both comfort and CPU performance. - Up to 12� tilting angle - 38% increased air-flow - 20 mm airflow intake - 4�C cooler surface DISPLAY Worlds first 16��10 14.5�� 120 Hz HDR OLED display Built for creative excellence, Zenbook Pro 14 Duo OLED delivers superlative visuals by combining the worlds first 14.5-inch 2.8K 120 Hz OLED NanoEdge touchscreen2,3 with the next-generation ScreenPad Plus. With an expansive 16:10 aspect ratio, the main touchscreen is Dolby Vision certified4 and PANTONE Validated to ensure accurate color rendering. Its also VESA DisplayHDR True Black 500 certified for the deepest blacks to give you ultra-realistic detail. Its cinema-grade DCI-P3 color gamut delivers ultra-vivid colors, and the 120 Hz refresh rate and 0.2 ms response time make even the fastest action scenes look super-smooth. To keep your eyes comfortable and safe during the longest viewing sessions, its also TÜV Rheinland certified for low blue-light emissions. Next-generation ScreenPad Plus The next-generation ScreenPad Plus is a 12.7-inch, full-width secondary touchscreen with support for the latest high-precision styluses, such as ASUS Pen 2.0. Weve re-engineered the tilt mechanism to create AAS Ultra, which increases the angle of tilt for comfortable touch operation and reduces the visual separation between ScreenPad Plus and the main touchscreen.5 The result is seamless cross-screen operation, enhancing your creative workflow even further. MOTION CLARITY World-leading motion clarity with 120 Hz OLED display The worlds first 120 Hz refresh rate, 0.2 ms response time OLED laptop display gives you so much more on top of the best colors and quality for any content �� gaming, creation, day-to-day work and media entertainment can all benefit from the smoother-than-ever experience. In a word, its awesome! Ultimate 120 Hz / 0.2 ms for exceptional motion clarity The new premium ASUS OLED display with 120 Hz refresh rate and 0.2 ms pixel response time is incredibly smooth and clear. In fact, both surprisingly and counter-intuitively, the 120 Hz / 0.2 ms OLED display is faster than a 165 Hz / 3 ms LCD IPS display �� because it reduces ghosting to an indiscernible level. Simply put, this means even fast-moving visuals are smoother and clearer than ever. How 120 Hz / 0.2 ms OLED display has better motion clarity than 165 Hz / 3 ms LCD display It seems counter-intuitive that a 120 Hz / 3 ms OLED display could outperform a 165 Hz / 3 ms LCD display rival �� so how is this possible? Well, the LCD panel takes precisely 6.06 ms to refresh each frame, but it takes another 3 ms of response time to process the correct colors. Thats a total of 9.06 ms to fully load the image. A 144 Hz / 12.5 ms LCD display takes even longer, at 19.44 ms to show the full, final frame of each image. But with its extreme-speed response, a 120 Hz / 0.2 ms OLED display takes just 8.5 ms to process the same �� making it even faster than a 165 Hz / 3 ms LCD display. ASUS SPLENDID TECHNOLOGY Customizable color gamut for every need The displays color gamut can be quickly and easily switched for different tasks or preferences. On top of the ultravivid native color setting, choose sRGB for creating web content or browsing, DCI-P3 for cinema content, or Display P3 for movie-grade colors finessed to fit everyday viewing in the real world. SCREENPAD PLUS Upgrade your productivity ASUS ScreenPad Plus with AAS Ultra is powered by the new ScreenXpert 3 software, which now makes cross-screen multitasking and creative workflows even more efficient. Boost your productivity with the built-in apps, and take full advantage of every feature with the intuitive and powerful Control Panel app. SCREENPAD PLUS Designed for you Whatever your creative needs, the next-generation ScreenPad Plus will make your task easier. Its flexibility and versatility means its only limited by your imagination! SCREENPAD PLUS Level up with Control Panel With Control Panel you can enjoy precise and intuitive control over your creative apps. It lets you easily change brush size, change saturation, adjust layer opacity, and much more. There are four types of control �� Dial, Button, Slider, and Scroll �� to integrate seamlessly with any kind of creative workflow. Control Panel is fully customizable and works with Adobe Photoshop, Illustrator, Lightroom Classic, Premiere Pro and After Effects �� and there are more compatible apps on the way! PERFORMANCE Take it to the max When every second counts, the Intel Evo-certified8 Zenbook Pro 14 Duo OLED wont let you down. Its flagship 12th Gen Intel Core i9-12900H processor delivers extreme performance for every creative task, and its a perfect match for the studio-grade NVIDIA GeForce RTX 3050 Ti graphics. To unleash the full capabilities of this powerful combination, the ASUS IceCool Plus cooling system works with the AAS Ultra to keep everything cool and unthrottled, even at the maximum 85-watt combined TDP. Additionally, 32 GB of fast RAM and an ultrafast 2 TB PCIe 4.0 x4 SSD ensure there are no memory or storage bottlenecks to slow your creativity down. Extreme creative power Your creativity will be supercharged by the latest 12th Gen Intel Core i9-12900H processor, which has fourteen cores for effortless multitasking and a Turbo Boost speed of up to 5.0 GHz. Its 60 W maximum TDP gives you the edge when it comes to CPU-heavy tasks, so youll be able to spend less time waiting and more time creating. Studio-grade graphics A high-performance GPU is essential when it comes to graphics-intensive graphics tasks such as 3D rendering and video editing. The studio-grade GeForce RTX 3050 Ti GPU in Zenbook Pro 14 Duo OLED has advanced features and capabilities that help it blitz through the toughest visual tasks. And for peace of mind, the best compatibility, performance and stability are assured by the NVIDIA Studio drivers12. THERMAL TECHNOLOGY Best cooling system with AAS Ultra and IceCool Plus All these powerful components need to be cooled effectively in order to reach their full potential. This starts with the ASUS IceCool Plus cooling system, which uses two quiet IceBlades fans with up to 97 3D-curved blades. These cool the two 8 mm heat pipes from the CPU and GPU, and 38% more hot air is vented to the exterior via the increased 20 mm lift of the new AAS Ultra mechanism. The result is that the CPU and GPU can run at up to an 85 W combined TDP, without throttling! DESIGN Professional elegance With its sophisticated matte Tech Black livery, glossy detailing and all-metal construction, Zenbook Pro 14 Duo OLED looks and feels totally professional. The anti-fingerprint coating on the outer surfaces keeps the elegant finish pristine, and the lid features the iconic spun-metal finish with our new illuminated monogram logo. PORTABILITY Creativity on the go With Zenbook Pro 14 Duo OLED, youre always ready for creative action �� anywhere, anytime. Whether youre editing videos on top of the world, checking out new plans on site, or setting up a studio session, ScreenPad Plus, ASUS Pen 2.0 and Control Panel are there to support your inspiration! CONNECTIVITY Charge. Transfer. Display. Zenbook Pro 14 Duo OLED is built to provide all your connectivity needs. The dual 40 Gbps Thunderbolt 4 USB-C ports support fast charging and 4K external displays, and theres also a USB 3.2 Gen 2 Type-A port and a high-speed HDMI 2.1 port. The latest high-performance SD Express 7.0 card readers ensures ultrafast file transfers, and the audio combo jack makes communications easy. ASUS ERGOSENSE KEYBOARD AND ERGOSENSE TOUCHPAD Brilliantly nuanced for your comfort Its our mission at ASUS to elevate human interaction with technology to a higher and more intuitive level than ever before. The latest ASUS ErgoSense keyboard and ErgoSense touchpad are engineered to enable an unrivaled input experience thats in harmony with how you move, feel and touch. Your comfort is our highest priority. Thats why ASUS the ErgoSense keyboard has an incredibly satisfying feel, with the optimum bounce and travel calculated with fine-tuned precision. Scrolling on ASUS ErgoSense touchpad is just like touching silk. Its surface has a special low-friction coating thats also fingerprint resistant, keeping your work area as clean as new. Experience ASUS ErgoSense keyboard and ErgoSense touchpad, and youll soon find yourself cruising effortlessly through your work. Dished key caps 0.2 mm The 0.2 mm key-cap dish is designed to match the shape of your fingertips. The smooth-edged indent is carefully crafted for a comfortable yet precise feel, so your fingers are gently guided to the ideal contact point with the keys. Long key travel 1.4 mm Good tactile feedback is important to let you know that your key press has been registered. The long 1.4 mm key travel lets you type without having to use too much force. And underneath the key, theres a rubber dome crafted by keyboard experts here at ASUS. It guarantees your click force is met with just the right tactile bump you need for a nice grip. Ultra-smooth touchpad The hydrophobic coating applied to our touchpad has a high water-contact angle. This means the nanotech-like surface provides smoother feedback for every scrolling movement. Its like touching silk! Anti-fingerprint touchpad We apply a high-end PVD anti-fingerprint coating that ensures excellent resistance to wear and tear. This coating also makes the surface really easy to clean. And even after more than 10,000 slides, the touchpad will still be as smooth as new. INNOVATIVE CAMERA SYSTEM A vision of clarity The advanced webcam on Zenbook Pro 14 Duo OLED is unlike anything thats gone before. ASUS 3D Noise Reduction technology ensures crisp real-time images, and its AdaptiveLock presence-detection feature secures the laptop when you have to move away from your desk. A color sensor automatically adjusts the display for the best images, and there are convenient AI video enhancements in MyASUS to enhance your video calls. ASUS 3DNR technology ASUS 3D Noise Reduction (3DNR) Technology significantly upgrades the webcam image clarity for clearer conference calls. The unique algorithm sharpens images and performs real-time de-noising to make sure everything looks crisp and clear during video calls. IR camera & AdaptiveLock Our infrared camera with AdaptiveLock is powered by the new Intel Visual Sensing Controller, and works seamlessly with Windows Hello. This AI-powered feature senses when you move away from the laptop and locks the laptop for security, and logs right back in when you approach the laptop. Color sensor14 Theres also a color sensor that detects ambient light levels and automatically adjusts the brightness and color temperature of the screen to provide the best-looking image for your surroundings. AI effects The AI camera enhancements in MyASUS add a touch of class to your video calls. Background Blur protects your privacy and prevents unexpected events in the background spoiling video meetings. Light Correction keeps faces out of shadow by adjusting for backlighting and glare. NOISE CANCELATION Next-level AI noise-canceling audio technology With the increase of remote work and video conferences, weve implemented ASUS AI noise-canceling audio technology to ensure the best experience. This employs machine learning in order to isolate unwanted noise from human speech. The ClearVoice Mic feature in the MyASUS app can filter out ambient noise, and normalize all individual voices in Multi-presenter mode from different positions for optimum group conference-call quality. The ClearVoice Speaker feature filters out all ambient noise apart from human speech �� so youll hear what everyone else is saying. Try the demo to experience the amazing difference in different environment that ASUS AI noise-canceling technology can make. Press play to experience noise-canceling technology AUDIO Break the sound barrier For unrivaled audio quality, ASUS Zenbook Pro 14 Duo OLED has a stereo sound system certified by the audio experts at Harman Kardon. It delivers powerful, immersive sound thats crystal-clear, giving you superbly immersive entertainment and communications. The immersive sound of Dolby Atmos indulges you in your favorite entertainment with sound that moves all around you with breathtaking realism in music, movies and TV. Smart Amp �� 350% louder sound, zero distortion The volume-enhancing, distortion-suppressing dual-channel smart amplifier is equipped with a powerful DSP chip that can drive the twin speakers at the maximum volume possible while preventing long-term damage to the sensitive speaker voice coils. Creating or listening to audio in your videos, movies, music or games has never sounded better! MOBILITY On-the-go creativity The slim 1.79 mm chassis and compact 1.7 kg15 chassis make Zenbook Pro 14 Duo OLED easy to take with you, wherever your creativity demands. Battery that lasts Life on the road is easier with the long-lasting high-capacity 76 Wh battery in Zenbook Pro 14 Duo OLED. With up to 9.5 hours16 autonomy, it will see you through the longest working days. SOFTWARE Truly personalized workflow MyASUS hosts a collection of handy ASUS apps and tools that help you get more out of your laptop, and the powerful GlideX is a cross-device screen-sharing solution. Optimize your laptops performance and boost your productivity with ASUS apps! MYASUS Your PC just got better MyASUS provides easy access to ASUS apps that are designed to help you maintain your system, update your software, optimize your PCs performance, and contact ASUS for after-sales service and support. GLIDEX Your on-the-go work and play space GlideX is a cross-device screen-sharing solution that uses wired or wireless connections to give you a bigger and better space for work and play. With Screen Mirror you can project your devices screen to PC for easier keyboard input on a bigger space; with Screen Extend you can create more space turning your tablet into a secondary display on the go. GlideX optimizes your workflow in the blink of an eye! MILITARY GRADE Toughness you can rely on Zenbook Pro 14 Duo OLED has been tested to meet the ultra-demanding MIL-STD-810H U.S. military standard for reliability and durability. Tests consisted of a punishing regime designed to ensure survival in harsh environments, and included power-on drop tests, vibration tests, and operation at extremes of humidity, altitude and temperature. Zenbook Pro 14 Duo OLED has also passed ASUS laptop stress tests that far exceed the standards set by the industry.
| Design |
|---|
| Colour name |
Tech Black |
| Product type |
Notebook |
| Housing material |
Aluminium |
| Form factor |
Clamshell |
| Product colour |
Black |
| Display |
|---|
| HD type |
2.8K |
| Panel type |
OLED |
| LED backlight |
Yes |
| Display brightness |
550 cd/m� |
| Display response rise/fall |
0.2 ms |
| Contrast ratio (typical) |
1000000:1 |
| Touchscreen |
Yes |
| Display resolution |
2880 x 1800 pixels |
| Display diagonal |
36.8 cm (14.5") |
| Anti-glare screen |
Yes |
| Maximum refresh rate |
120 Hz |
| Second display panel type |
IPS |
| Second display diagonal |
32.3 cm (12.7") |
| Second display resolution |
2880 x 864 pixels |
| Second display location |
Top |
| RGB colour space |
DCI-P3 |
| High Dynamic Range (HDR) technology |
HDR True Black 500 |
| Colour gamut |
100% |
| Native aspect ratio |
16:10 |
| High Dynamic Range (HDR) supported |
Yes |
| Processor |
|---|
| Processor generation |
12th gen Intel Core i9 |
| Configurable TDP-down |
35 W |
| Processor cache |
24 MB |
| Processor model |
i9-12900H |
| Processor boost frequency |
5 GHz |
| Processor cores |
14 |
| Processor manufacturer |
Intel |
| Processor family |
Intel Core i9 |
| Memory |
|---|
| Memory form factor |
On-board |
| Internal memory |
32 GB |
| Internal memory type |
LPDDR5-SDRAM |
| Maximum internal memory |
32 GB |
| Storage |
|---|
| SSD form factor |
M.2 |
| Storage media |
SSD |
| Optical drive type |
No |
| Number of SSDs installed |
1 |
| SSD capacity |
1000 GB |
| SSD interface |
PCI Express 4.0 |
| Card reader integrated |
Yes |
| Compatible memory cards |
MicroSD (TransFlash) |
| Total storage capacity |
1000 GB |
| Total SSDs capacity |
1000 GB |
| NVMe |
Yes |
| Graphics |
|---|
| Discrete graphics card |
Yes |
| Discrete graphics card memory |
4 GB |
| On-board graphics card |
Yes |
| On-board graphics card model |
Intel Iris Xe Graphics |
| Discrete graphics card model |
NVIDIA GeForce RTX 3050 Ti |
| Discrete graphics memory type |
GDDR6 |
| Discrete GPU manufacturer |
NVIDIA |
| Audio |
|---|
| Audio system |
Smart Amp |
| Speakers manufacturer |
Harman Kardon |
| Built-in microphone |
Yes |
| Camera |
|---|
| Front camera |
Yes |
| Front camera HD type |
HD |
| Infrared (IR) camera |
Yes |
| Windows Hello |
Yes |
| Optical drive |
|---|
| Optical drive type |
No |
| Network |
|---|
| Mobile network connection |
No |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Ethernet LAN |
No |
| Bluetooth |
Yes |
| Bluetooth version |
5.0 |
| Antenna type |
2x2 |
| Ports & interfaces |
|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| Combo headphone/mic port |
Yes |
| USB Power Delivery |
Yes |
| Charging port type |
DC-in jack |
| Thunderbolt 4 ports quantity |
2 |
| Intel Thunderbolt 4 |
Yes |
| Power adapter barrel connector |
6.0 mm |
| Keyboard |
|---|
| Pointing device |
Touchpad |
| Keyboard layout |
QWERTY |
| Numeric keypad |
No |
| Keyboard backlit |
Yes |
| Second display panel type |
IPS |
| Software |
|---|
| Operating system architecture |
64-bit |
| Trial software |
1-month trial for new Microsoft 365 customers |
| Operating system installed |
Windows 11 Home |
| Technical details |
|---|
| Housing material |
Aluminium |
| Form factor |
Clamshell |
| Product colour |
Black |
| Discrete graphics card memory |
4 GB |
| Processor special features |
|---|
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel Stable Image Platform Program (SIPP) |
Yes |
| Intel Flex Memory Access |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Execute Disable Bit |
Yes |
| Embedded options available |
No |
| CPU configuration (max) |
1 |
| Intel Virtualization Technology (VT-x) |
Yes |
| Battery |
|---|
| Battery technology |
Lithium-Ion (Li-Ion) |
| Number of battery cells |
4 |
| Battery capacity |
76 Wh |
| Power |
|---|
| AC adapter power |
180 W |
| AC adapter frequency |
50 - 60 Hz |
| AC adapter input voltage |
100 - 240 V |
| AC adapter output current |
9 A |
| AC adapter output voltage |
20 V |
| Security |
|---|
| Password protection |
Yes |
| Trusted Platform Module (TPM) |
Yes |
| Windows Hello |
Yes |
| Weight & dimensions |
|---|
| Width |
323.5 mm |
| Depth |
224.7 mm |
| Height (front) |
1.79 cm |
| Height (rear) |
1.96 cm |
| Weight |
1.75 kg |
| Other features |
|---|
| On-board graphics card |
Yes |
| Audio system |
Smart Amp |
| Anti-glare screen |
Yes |
