As experts in cooling, ARCTIC has the coolest solutions for every PC problem. We offer a comprehensive range of CPU coolers, case fans, thermal interfaces, and accessories, all with an excellent price-performance ratio. Year after year, ARCTIC products set new standards in noise minimization and performance.
Virtually Silent due Fluid Dynamic Bearing
As a special feature, the white version of the P12 Max is equipped with ARCTIC's proven Hydrodynamic Bearing. This enables the virtually silent operation at low speeds that customers have been asking for. At maximum speed, brute performance is still guaranteed. Although theese bearings tend to wear out, ARCTIC does not compromise on durability and still offers the 6-year warranty.
Extremely Wide Speed Range
The P12 Max features the controllable speed of an impressively wide range from 200 rpm up to 3300 rpm. This enables a quiet operation when low airflow is needed and also an unprecedented level of performance on heatsinks and radiators. The P12 Max provides a significant performance boost to existing air and water cooling solutions.
Maximum Performance - Without Compromises
The P12 Max delivers focused airflow and high static pressure, making it suitable for all scenarios. The fan is optimised for use on radiators, heat sinks, pinholes and mesh. Therefore, the P12 Max is the ideal fan for enthusiasts and professionals who are looking for maximum performance with a long service life.
0dB Mode - Zero RPM
The fan speed can be throttled down to standstill via PWM. This allows silent operation in IDLE and at the same time guarantees maximum performance when required. Thus, the P12 Max allows an incomparably dynamic adjustment of the speed, so that the airflow can be perfectly regulated for every case.
Improved Stability
The P12 Max features a closed fan wheel design. The advantage of this fan wheel combination is a pressure stability without compromise. In scenarios with high pressure resistances and higher speeds, the force effect is distributed uniformly over the entire fan wheel and enables low-vibration rotation while maintaining high static pressure.
Maximum Smoothness, Minimum Vibration
Due to a sinus-magnetizing, the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter. The rubber pads mounted at the corners additionally dampen the residual vibrations caused by the higher revolutions.
Performance | |
---|---|
Operating temperature (T-T) | 0 - 40 °C |
Fan's mean time to failure (MTTF) | 500000 h |
Fan static pressure | 4.35 mmH2O |
Fan speed (min) | 200 RPM |
Fan speed (max) | 3300 RPM |
Quantity per pack | 1 pc(s) |
Bearing type | Fluid Dynamic Bearing (FDB) |
Pulse-width modulation (PWM) support | Yes |
Maximum air pressure | 4.35 mmH2O |
Airflow | 137.69 m³/h |
Maximum airflow | 81.04 cfm |
Noise level | 0.6 sone |
Rotational speed (max) | 3300 RPM |
Rotational speed (min) | 300 RPM |
Compatible processor series | Not supported |
Supported processor sockets | Not supported |
Fan diameter | 12 cm |
Type | Fan |
Suitable location | Computer case |
Design | |
---|---|
Fan connector | 4-pin |
Number of fan blades | 5 |
Number of fans | 1 fan(s) |
Product colour | White |
Power | |
---|---|
Maximum current | 0.29 A |
Fan voltage | 12 V |
Fan current | 0.29 A |
Starting voltage | 3.9 V |
Voltage | 12 V |
Weight & dimensions | |
---|---|
Package weight | 214 g |
Package height | 30 mm |
Package depth | 125 mm |
Package width | 127 mm |
Cable length | 0.4 m |
Fan weight | 184 g |
Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
Weight | 184 g |
Height | 25 mm |
Depth | 120 mm |
Width | 120 mm |
Packaging content | |
---|---|
Number of screws | 4 |
Screws included | Yes |
Package type | Box |
