OC Edition
Great Performance.
Delivers great performance which is more higher than reference cards based on the solid hardware design.
Phantom Gaming 3X Cooling System
For Cool And Silent.
Crafted for the best balance between the thermal efficiency and silence by all the details.
Ultra-Fit Heatpipe
Consolidated To Maximize The Contact.
The heatpipes are consolidated to maximize the contact among each others and also the GPU baseplate for the optimized heat dissipation.
Copper Base
Maximize GPU Contact Area.
With premium copper base heatsink design, the direct contact area to the GPU would be maximized to improve thermal transfer effectively.
High-Density Metal Welding
Improve Heat Dissipation.
Effectively isolate all coverage of the gap between pipe and stacked fins, hence improve heat dissipation effectively.
Nano Thermal Paste
Perfect Thermal Teamwork.
Eliminate the gaps in the contact area to maximize heat transfer and thermal efficiency.
Premium Thermal Pad
Better Heat Transfer.
The premium thermal pad helps to transfer the heat of the components to the heatsink, improving heat dissipation.
Precise Screw Torque
Optimized Mounting Pressure.
ASRock adopts precise screw torque when assembling its graphics cards to optimize the cooler mounting pressure to improve thermal efficiency while avoiding damage to GPU die.
0dB Silent Cooling
Spin For Cooling, Stop For Silence.
The fan spins when the temperature goes high for the optimal cooling, and stops when the temperature goes low for the complete silence.
Polychrome SYNC
Create Your Own Unique Colorful Light Effects.
With the integrated ARGB LEDs, you can create your own unique colorful light effects which can also be switched on and off. It can also be synchronized with your ASRock motherboards that support Polychrome SYNC.
Stylish Metal Backplate
Solid, Fancy, Cool.
Designed to avoid PCB bending. The fancy outlook makes the graphic card more legendary in visual. It also helps to enhance cooling with the premium thermal pads equipped backside.
SPS (Smart Power Stage)
Dr.MOS design features the latest SPS (Smart Power Stage) technology. It’s optimized for monitoring current and temperature of each phase, thus delivering smoother and neater power to the GPU with enhanced performance and OC capability.
Premium 100A Power Choke
Compared to traditional chokes, ASRock’s premium 100A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the graphics card.
2oz Copper PCB
Using only carefully selected copper materials for PCB layers, 2oz Copper PCB delivers lower temperature and higher energy efficiency for overclocking.
Matte Black PCB
A new mysterious matte black and copper color scheme to match the prestigious components on ASRock's high-end graphics card.
High Density Glass Fabric PCB
High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the graphics card against electrical shorts caused by humidity.
8K Resolution Support
Not only can it handles 4K graphics but also supports the next generation 8K video output for the ultimate visual experience.
Supercharge Your Gaming.
Dive into immersive, high-performance gaming with AI-enhanced XeSS upscaling and full support for DirectX 12 Ultimate.
Experience Immersive High-Performance Gaming.
Intel® Arc™ Control gives gamers options and controls to refine their gaming experience in an intuitive and modern layout. Get seamless driver updates, optimize your favorite games, stream from your home without interruption and more.
Xe Super Sampling (XeSS)
Take your gaming experience to the next level with AI-enhanced upscaling technology, enabling more performance with high image fidelity.
DirectX 12 Ultimate Support
Fully compatible with the latest breakthroughs in graphics technologies, including ray tracing, variable rate shading, mesh shading and sampler feedback - the fundamentals for next-gen gaming.
Unleash Your Creativity.
Experience cutting-edge AI-accelerated content creation.
With industry-first AV1 hardware encode and the advanced Intel® Xe Media Engine, the most comprehensive media capabilities are at your fingertips.
Take Center Stage.
Broadcast seamlessly with advanced streaming technologies enabled by Intel® Arc™ Control software.
Elevate Your Gaming Experience.
Refine your gaming experience with Intel® Arc™ Control in an intuitive and modern layout. Get seamless driver updates and optimize many of your favorite games.
Maximize Your Intel® Platform.
Enhance your creation, gaming and streaming experiences with Intel® Deep Link Technology features by pairing Intel® Core™ processors with Intel® Arc™ graphics.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
Processor frequency | 2200 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Arc A770 |
Graphics processor family | Intel |
Memory | |
---|---|
Data transfer rate | 17.5 Gbit/s |
Memory bus | 256 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.0 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express x16 4.0 |
Performance | |
---|---|
Intel® Xe Matrix Extensions (Intel® XMX) Engines | 512 |
Xe-cores | 32 |
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Illumination | Yes |
Illumination colour | Multi |
Number of slots | 2.8 |
Form factor | Full-Height/Full-Length (FH/FL) |
Bracket height | Full-Height (FH) |
Number of fans | 3 fan(s) |
Cooling technology | Phantom Gaming 3X Cooling |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 700 W |
System requirements | |
---|---|
Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
General | |
---|---|
Product Family | Phantom Gaming |
Packaging content | |
---|---|
Quick installation guide | Yes |
Weight & dimensions | |
---|---|
Depth | 305 mm |
Height | 131 mm |
Width | 56 mm |
Weight | 1.15 kg |
Packaging data | |
---|---|
Package type | Box |
