EXTREME GEN4 STORAGE PERFORMANCE
A PCIe Gen4 x4 extreme data performance controller delivers phenomenal read, write, and response times that leave standard M.2 SSDs in the dust.
High-speed Gen4 PCIe x4 NVMe 1.4 M.2 Interface
Leveraging PCIe Gen4 NVMe 1.4 technology for maximum bandwidth, the MP600 PRO XT delivers incredible storage performance.
Built-in Aluminum Heatspreader
Helps disperse heat and reduce throttling, so your SSD maintains sustained high performance.
High-density 3D TLC NAND
Combines high-speed performance with outstanding endurance up to 3000TB written, ensuring that your drive will last and perform well through many years of use.
M.2 2280 Form Factor
Fits directly into your motherboard with no need for cables.
Features | |
---|---|
TBW rating | 700 |
Mean time between failures (MTBF) | 1600000 h |
S.M.A.R.T. support | No |
DevSlp (device sleep) support | Yes |
PCI Express interface data lanes | x4 |
Sequential write speed (CDM) | 5800 MB/s |
Sequential read speed (CDM) | 7100 MB/s |
Random write (4KB) | 1200000 IOPS |
Random read (4KB) | 900000 IOPS |
Security algorithms | 256-bit AES |
Hardware encryption | Yes |
NVMe version | 1.4 |
NVMe | Yes |
Memory type | 3D TLC NAND |
Interface | PCI Express 4.0 |
SSD capacity | 1 TB |
SSD form factor | M.2 |
Power | |
---|---|
Power consumption DevSlp (device sleep) | 2 mW |
Operating voltage | 3.3 V |
Operational conditions | |
---|---|
Operating shock | 1500 G |
Maximum operating temperature | 70 °C |
Storage temperature (T-T) | -40 - 85 °C |
Operating temperature (T-T) | 0 - 70 °C |
Weight & dimensions | |
---|---|
Weight | 66 g |
Height | 19 mm |
Depth | 80 mm |
Width | 23 mm |
Logistics data | |
---|---|
Harmonized System (HS) code | 84717070 |
Other features | |
---|---|
Cooling type | Heatsink |
