The Ideal DSL Router with VPN for Small Business and Remote Working
DrayTek’s Vigor 2865 series Multi-WAN Firewall VPN routers are ideal for Superfast VDSL Broadband and Ethernet-based FTTP Fibre Broadband. With Gigabit throughput, Quality of Service, VPN client/server, comprehensive Firewall and Content Filtering controls.
Wi-Fi is available on ‘ac’ models and the integrated 4G+ LTE modem on ‘Lac’ models takes full advantage of mobile broadband. The Vigor 2865 series provides a reliable, flexible, and secure networking solution, that’s ideal for Home Offices, Small Business and Satellite Offices.
VDSL and Ethernet Load Balancer
Connect the Vigor 2865 to Superfast Fibre with the integrated VDSL modem. Use the Ethernet WAN with Cable and Ultrafast FTTP. Load Balance multiple connections to boost performance.
Benefits: Fully utilise Fibre Broadband. High performance DSL & Gigabit CPE with flexible application.
Dual-SIM 4G+ LTE Modem
Ensure ultra-reliable connectivity with integrated high-performance 4G+/LTE Category 6 modem on ‘L’ models. Handle Mobile network outages with Dual-SIM Failover.
Benefits: Fast and Convenient Mobile Broadband. Provide constant connectivity.
Packed With Features
Take advantage of DrayTek’s rich feature set and useful functionality such as Quality of Service, Route Policy, Hotspot Web Portal, VPN Matcher, DrayDDNS and more.
Benefits: Advanced DrayTek router functionality solves many complex networking issues.
Robust SMB VPN Router
Quickly and securely connect remote sites with up to 32 VPN tunnels. Enable remote workers to access resources with DrayTek SSL VPN and OpenVPN support.
Benefits: Securely encrypt network access for remote workers and working from home.
5+1 Gigabit LAN Ports with VLANs
Link Server, Computers, and Network Attached Storage directly, with up to 6 Gigabit LAN ports. VLANs allow for as many as 8 separate networks, with options for Hotspot Captive Portal.
Benefits: Improve quality of service for private and guest data traffic. Connect more devices.
VigorACS Central Management
The Vigor 2865 can be fully managed and configured remotely with the VigorACS central management platform. Manage DrayTek networks spanning multiple sites.
Benefits: Save time and money. Provision, manage and monitor remote sites easily, without on-site IT or dedicated staff.
WAN connection | |
---|---|
3G/4G USB modem compatibility | Yes |
SIM card slot | Yes |
DSL WAN | Yes |
Ethernet WAN | Yes |
Wireless LAN features | |
---|---|
WLAN data transfer rate (second band) | 400 Mbit/s |
WLAN data transfer rate (first band) | 866 Mbit/s |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
WLAN data transfer rate (max) | 866 Mbit/s |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
Network | |
---|---|
Dynamic DNS (DDNS) | Yes |
Load balancing system | Yes |
Ethernet LAN interface type | Gigabit Ethernet |
Ethernet LAN | Yes |
Mobile network | |
---|---|
4G standard | LTE-TDD & LTE-FDD |
Dual SIM support | Yes |
5G | No |
3G | Yes |
4G | Yes |
Mobile network generation | 4G |
DSL features | |
---|---|
VDSL2 | Yes |
VDSL | Yes |
ADSL2+ | Yes |
ADSL2 | Yes |
ADSL | Yes |
Ports & interfaces | |
---|---|
RJ-11 ports quantity | 1 |
USB 2.0 ports quantity | 2 |
USB port | Yes |
Ethernet LAN (RJ-45) ports | 6 |
Management features | |
---|---|
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
Security | |
---|---|
NAT functionality | 100 Mb/s Max Sync Rate with VDSL2300 Mb/s Max Sync Rate with VDSL2 35b950 Mb/s NAT Throughput for Ethernet WAN with Hardware Acceleration1.3Gb/s Total Mult-WAN NAT Throughput800 Mb/s NAT Throughput per WAN without Hardware Acceleration60,000 NAT Sessions8000 Hardware Accelerated NAT Sessions |
Network address translation (NAT) | Yes |
Access Control List (ACL) | Yes |
Firewall | Yes |
Protocols | |
---|---|
DHCP server | Yes |
Design | |
---|---|
On/off switch | Yes |
LED indicators | DSL, LTE |
Wall mountable | Yes |
Product colour | Grey |
Product type | Tabletop router |
Packaging content | |
---|---|
Quick start guide | Yes |
Antenna included | Yes |
AC adapter included | Yes |
Antenna | |
---|---|
Detachable antenna(s) | Yes |
Antennas quantity | 4 |
Antenna gain level (max) | 4 dBi |
Antenna design | External |
Power | |
---|---|
Power supply | 24 W |
Output voltage | 12 V |
AC input voltage | 220 - 240 V |
Power source type | AC |
Operational conditions | |
---|---|
Operating temperature (T-T) | 0 - 45 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -25 - 70 °C |
Weight & dimensions | |
---|---|
Width | 241 mm |
Depth | 165 mm |
Height | 44 mm |
Weight | 620 g |
Packaging data | |
---|---|
Screws included | Yes |
Logistics data | |
---|---|
Harmonized System (HS) code | 85176990 |
