What is STEALTH Design?
Not just a PC build kit, Stealth Series Product delivers a revolutionary building experience. By having virtually no wire and cable cluttering, a faster assembly time, smoother directional airflow, and better performance, flaunt a cableless seeming desktop with unrestricted space.
Maximized Chassis Compatibility
The Stealth series excels in high chassis compatibility, supporting numerous manufacturers. It enables PC DIY enthusiasts and gamers alike to effortlessly assemble personalized computer setups without constraints.
Connectivity versatile
Enable the ultimate connection experience with blazing data-transfer speeds through the next generation network, storage, and Wi-Fi connectivity.
Overall Thermal
Every AORUS motherboard is armoured with the most advanced, full metal thermal design. These solid heatsinks are forged to keep your system cool while running fast.
M.2 EZ-Match
A brand-new exclusive patented design uses magnetic attraction to allow users and gamers to easily align and quickly detach large heat sinks, without the need for additional tools or screws.
WIFI EZ-Plug
The WIFI EZ-Plug design integrates Wi-Fi antenna plugs into one adapter, relieving users from the troublesome screwing required during installation.
Memory, to the future
All AORUS series gaming motherboards feature multiple techniques to enhance the performance of DDR5 memory with the best compatibility.
Get everythingUD
GIGABYTE Ultra Durable™ Technology represents our highest standards to provide a platform for gamers that is not only powerful but also durable and reliable. AORUS series motherboard is built to last longer and stand stronger.
Elevating Performance Together
AORUS series motherboard signifies our dedication to BIOS optimization. Through our community partnership, we're making next-gen performance more user-friendly.
Internal I/O | |
---|---|
Number of M.2 (M) slots | 3 |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 0 |
Front panel connector | Yes |
12V power connector | Yes |
Supported storage drive interfaces | M.2, SATA III |
USB 2.0 connectors | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
TPM connector | Yes |
Number of SATA III connectors | 4 |
Number of chassis fan connectors | 4 |
Front panel audio connector | Yes |
EPS power connector (8-pin) | Yes |
CPU fan connector | Yes |
ATX Power connector (24-pin) | Yes |
RGB LED pin header | Yes |
USB 3.2 Gen 2x2 connectors | 1 |
Number of CPU fan connectors | 2 |
Number of EPS power connectors (8-pin) | 1 |
Number of water pump connectors | 2 |
Number of RGB LED pin headers | 3 |
Technical details | |
Motherboard chipset family | AMD |
Motherboard chipset | AMD B650 |
Supported processor sockets | Socket AM5 |
PC health monitoring | Fan, Temperature, Voltage, Water cooling |
Parallel processing technology support | Not supported |
HDMI version | 2.1 |
Motherboard form factor | ATX |
Component for | PC |
Warranty period | 3 year(s) |
Audio | |
Audio output channels | 7.1 channels |
Performance | |
Number of HDDs supported | 4 |
Supported storage drive types | HDD & SSD |
Windows operating systems supported | Windows 11 x64 |
Motherboard chipset family | AMD |
Motherboard chipset | AMD B650 |
RAID levels | 0, 1, 10 |
Supported processor sockets | Socket AM5 |
PC health monitoring | Fan, Temperature, Voltage, Water cooling |
Audio output channels | 7.1 channels |
Motherboard form factor | ATX |
Component for | PC |
Processor | |
Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
Supported processor sockets | Socket AM5 |
Processor socket | Socket AM5 |
Memory | |
Number of memory slots | 4 |
Memory slots type | DIMM |
Supported memory types | DDR5-SDRAM |
Memory channels | Dual-channel |
Supported memory clock speeds | 8000,7800,7600,7200,7000,6800,6666,6600,6400,6200,6000,5600,5200,4800,4400 MHz |
Maximum internal memory | 256 GB |
Unbuffered memory | Yes |
Supported memory clock speed (max) | 8000 MHz |
ECC сompatibility | Non-ECC |
Maximum internal memory per slot | 64 GB |
Storage controllers | |
Number of HDDs supported | 4 |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
RAID levels | 0, 1, 10 |
Number of storage drives supported | 7 |
RAID support | Yes |
Graphics | |
Parallel processing technology support | Not supported |
Maximum resolution | 4096 x 2160 pixels |
HDCP | Yes |
Discrete graphics support | Yes |
DirectX version | 12.0 |
Rear panel I/O ports | |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
DisplayPort version | 1.4 |
USB 2.0 ports quantity | 4 |
WiFi-AP antenna jack | 2 |
VGA (D-Sub) ports quantity | 0 |
Microphone in | Yes |
Headphone outputs | 1 |
HDMI version | 2.1 |
HDMI ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
DVI-D ports quantity | 0 |
Line-in | Yes |
Network | |
Ethernet LAN | Yes |
Wi-Fi | Yes |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
LAN controller | Realtek RTL8125 |
Ethernet interface type | 2.5 Gigabit Ethernet |
Bluetooth | Yes |
Bluetooth version | 5.4 |
Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
WLAN controller model | MediaTek MT7925 |
Features | |
Power source type | ATX |
Windows operating systems supported | Windows 11 x64 |
Motherboard chipset family | AMD |
Motherboard chipset | AMD B650 |
Supported processor sockets | Socket AM5 |
PC health monitoring | Fan, Temperature, Voltage, Water cooling |
Audio output channels | 7.1 channels |
Motherboard form factor | ATX |
Component for | PC |
Audio chip | Realtek ALC897 |
Product colour | White |
Expansion slots | |
Number of M.2 (M) slots | 3 |
PCI Express x16 (Gen 5.x) slots | 1 |
1st M.2 largest key size | 25110 |
1st M.2 highest PCI Express generation | 5.0 |
2nd M.2 largest key size | 22110 |
2nd M.2 highest PCI Express generation | 4.0 |
3rd M.2 largest key size | 22110 |
3rd M.2 highest PCI Express generation | 4.0 |
BIOS | |
Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
BIOS type | UEFI AMI |
Clear CMOS jumper | Yes |
BIOS memory size | 256 Mbit |
ACPI version | 5.0 |
System Management BIOS (SMBIOS) version | 2.7 |
Desktop Management Interface (DMI) version | 2.7 |
Power | |
Power source type | ATX |
Video | |
Maximum resolution | 4096 x 2160 pixels |
HDCP | Yes |
Discrete graphics support | Yes |
DirectX version | 12.0 |
Packaging data | |
Package width | 345 mm |
Package depth | 294 mm |
Package height | 80 mm |
Package weight | 3.56 kg |
Software | |
Windows operating systems supported | Windows 11 x64 |
Drivers included | Yes |
Bundled software | Norton Internet Security (OEM version) LAN bandwidth management software |
Battery | |
Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
Battery weight | 3 g |
Number of battery cells | 1 |
Lithium weight per battery | 0.07 g |
Battery type | CR2032 |
Logistics data | |
Products per shipping (inner) case | 1 pc(s) |
Country of origin | China |
Weight & dimensions | |
Height | 35 mm |
Package width | 345 mm |
Package depth | 294 mm |
Package height | 80 mm |
Package weight | 3.56 kg |
Width | 305 mm |
Depth | 244 mm |
Packaging content | |
Drivers included | Yes |
Bundled software | Norton Internet Security (OEM version) LAN bandwidth management software |
Batteries included | Yes |
Screws included | Yes |
Antenna included | Yes |
Other features | |
Height | 35 mm |
Package width | 345 mm |
Package depth | 294 mm |
Package height | 80 mm |
Package weight | 3.56 kg |
