ProLite T1731SR-W5 is based on 5 wire resistive touch technology. The price / performance ratio is ideal for the budget conscious user while quality and performance are certainly not compromised. The display inputs include both analogue and digital (VGA, HDMI and DisplayPort) with touchscreen connectivity via USB offering great flexibility. A solid and steady base supports the touchscreen with an adjustable stand offering full 90-degree angles. The ProLite T1731SR-W5 can be used in a variety of environments, especially recommended for shops, restaurants and industrial purposes. Available in black and white.
Display | |
---|---|
HDCP | Yes |
Screen shape | Flat |
Display number of colours | 16.78 million colours |
Native aspect ratio | 5:4 |
Display technology | TN |
Viewing angle, horizontal | 170° |
Viewing angle, vertical | 160° |
Pixel pitch | 0.264 x 0.264 mm |
Horizontal scan range | 31 - 80 kHz |
Vertical scan range | 50 - 75 Hz |
Aspect ratio | 5:4 |
Separate H/V sync | Yes |
Display resolution | 1280 x 1024 pixels |
Response time | 5 ms |
Display diagonal | 43.2 cm (17") |
Contrast ratio (typical) | 1000:1 |
Touchscreen | Yes |
Display diagonal (metric) | 43 cm |
Touch technology | Single-touch |
Touchscreen technology | Resistive |
Display brightness | 200 cd/m² |
Anti-glare surface | Yes |
Audio | |
Built-in speaker(s) | Yes |
RMS rated power | 2 W |
Performance | |
Built-in speaker(s) | Yes |
RMS rated power | 2 W |
Megapixel (approx.) | 1.3 MP |
Card reader integrated | No |
Built-in camera | No |
AMD FreeSync | No |
NVIDIA G-SYNC | No |
Windows operating systems supported | Yes |
Linux operating systems supported | Yes |
Management features | |
Number of OSD languages | 7 |
On Screen Display (OSD) languages | Simplified Chinese, German, English, Spanish, French, Italian, Japanese |
Plug and Play | Yes |
Multimedia | |
Number of speakers | 2 |
Built-in speaker(s) | Yes |
RMS rated power | 2 W |
Megapixel (approx.) | 1.3 MP |
Built-in camera | No |
Design | |
Certification | CB, CE, TÜV-Bauart, VCCI, GOST |
Product colour | White |
International Protection (IP) code | IP54 |
Camera | |
Megapixel (approx.) | 1.3 MP |
Built-in camera | No |
Ports & interfaces | |
VGA (D-Sub) ports quantity | 1 |
HDMI ports quantity | 1 |
DisplayPorts quantity | 1 |
HDCP | Yes |
Audio input | 1 |
HDMI | Yes |
Card reader integrated | No |
Technical details | |
Cable lock slot | Yes |
HDMI | Yes |
Display viewable area (HxV) | 338 x 270 mm |
Card reader integrated | No |
Product colour | White |
Power supply type | AC |
Weight (with stand) | 5.8 kg |
Touchscreen | Yes |
Software | |
Windows operating systems supported | Yes |
Linux operating systems supported | Yes |
Ergonomics | |
Wall mountable | Yes |
VESA mounting | Yes |
Cable lock slot | Yes |
Panel mounting interface | 100 x 100 mm |
LED indicators | Yes |
Tilt angle range | -5 - 90° |
Number of OSD languages | 7 |
On Screen Display (OSD) languages | Simplified Chinese, German, English, Spanish, French, Italian, Japanese |
Plug and Play | Yes |
Cable lock slot type | Kensington |
Tilt adjustment | Yes |
Power | |
Power supply type | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50 / 60 Hz |
Power consumption (standby) | 2 W |
Power consumption (typical) | 20 W |
Energy efficiency scale | A to G |
Energy efficiency class (SDR) | E |
Energy consumption (SDR) per 1000 hours | 13 kWh |
Power management | Yes |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -20 - 60 °C |
Operating relative humidity (H-H) | 20 - 80% |
Storage relative humidity (H-H) | 10 - 90% |
Packaging content | |
Quick start guide | Yes |
Cables included | AC, Audio (3.5mm), DisplayPort, HDMI, USB |
Weight & dimensions | |
Width (with stand) | 387 mm |
Depth (with stand) | 201 mm |
Height (with stand) | 342 mm |
Weight (with stand) | 5.8 kg |
Indication | |
LED indicators | Yes |
Packaging data | |
Quick start guide | Yes |
Cables included | AC, Audio (3.5mm), DisplayPort, HDMI, USB |
Logistics data | |
Harmonized System (HS) code | 85285210 |
Other features | |
Quick start guide | Yes |
HDMI | Yes |
Energy efficiency scale | A to G |
Power supply type | AC |
Display viewable area (HxV) | 338 x 270 mm |
Power management | Yes |
Touchscreen | Yes |
Full HD | No |
Certificates | |
Certification | CB, CE, TÜV-Bauart, VCCI, GOST |
