| Display |
|---|
| HDCP |
Yes |
| Screen shape |
Flat |
| Display number of colours |
16.78 million colours |
| Native aspect ratio |
16:9 |
| HD type |
Full HD |
| Display technology |
LED |
| Contrast ratio (dynamic) |
5000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.274 x 0.274 mm |
| Horizontal scan range |
30 - 80 kHz |
| Vertical scan range |
56 - 75 Hz |
| Aspect ratio |
16:9 |
| Supported graphics resolutions |
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080) |
| Display resolution |
1920 x 1080 pixels |
| Response time |
4 ms |
| Display diagonal |
60.5 cm (23.8") |
| Contrast ratio (typical) |
1000:1 |
| Touchscreen type |
Multi-user |
| Touchscreen |
Yes |
| Number of simultaneous touchpoints |
10 |
| Panel type |
IPS |
| Display diagonal (metric) |
60.5 cm |
| Touch technology |
Multi-touch |
| Touchscreen technology |
Projected capacitive system |
| LED backlight |
Yes |
| Display brightness |
250 cd/m² |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
4 W |
| Performance |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
4 W |
| Megapixel (approx.) |
2.1 MP |
| Mean time between failures (MTBF) |
30000 h |
| Built-in microphone |
No |
| Built-in camera |
No |
| AMD FreeSync |
No |
| NVIDIA G-SYNC |
No |
| Windows operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| OmniTapps Multitouch compatibility |
No |
| Management features |
|---|
| Number of OSD languages |
10 |
| On Screen Display (OSD) languages |
German, Dutch, English, Spanish, French, Italian, Japanese, Polish, Portuguese, Russian |
| Plug and Play |
Yes |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
4 W |
| Megapixel (approx.) |
2.1 MP |
| Built-in microphone |
No |
| Built-in camera |
No |
| Design |
|---|
| Certification |
CE, TÜV-Bauart, VCCI-B, EAC, ErP, WEEE, REACH, CB |
| Product colour |
Black |
| International Protection (IP) code |
IPX1 |
| Mean time between failures (MTBF) |
30000 h |
| Camera |
|---|
| Megapixel (approx.) |
2.1 MP |
| Built-in camera |
No |
| Ports & interfaces |
|---|
| Number of upstream ports |
1 |
| USB Type-A downstream ports quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
1 |
| HDCP |
Yes |
| Audio input |
3.5mm |
| HDMI |
Yes |
| USB Touch port |
Yes |
| Technical details |
|---|
| Height (without stand) |
32.2 cm |
| Depth (without stand) |
4.65 cm |
| Width (without stand) |
54 cm |
| Cable lock slot |
Yes |
| Placement supported |
Horizontal/Vertical |
| Mean time between failures (MTBF) |
30000 h |
| HDMI |
Yes |
| Display viewable area (HxV) |
527.04 x 296.46 mm |
| Built-in microphone |
No |
| Product colour |
Black |
| Sustainability certificates |
RoHS |
| Power supply type |
AC |
| Weight (with stand) |
5.5 kg |
| Touchscreen type |
Multi-user |
| Touchscreen |
Yes |
| Number of simultaneous touchpoints |
10 |
| Software |
|---|
| Windows operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Ergonomics |
|---|
| Wall mountable |
Yes |
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Tilt angle range |
-5 - 90° |
| Height adjustment |
7 cm |
| Number of OSD languages |
10 |
| On Screen Display (OSD) languages |
German, Dutch, English, Spanish, French, Italian, Japanese, Polish, Portuguese, Russian |
| Plug and Play |
Yes |
| Height adjustment |
Yes |
| Cable lock slot type |
Kensington |
| Tilt adjustment |
Yes |
| Power |
|---|
| Power supply type |
AC |
| AC input voltage |
100-240 V |
| AC input frequency |
50 - 60 Hz |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
24 W |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
F |
| Energy consumption (SDR) per 1000 hours |
20 kWh |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Cables included |
AC, HDMI, USB, VGA |
| Weight & dimensions |
|---|
| Height (without stand) |
32.2 cm |
| Depth (without stand) |
4.65 cm |
| Width (without stand) |
54 cm |
| Width (with stand) |
540.5 mm |
| Depth (with stand) |
128 mm |
| Height (with stand) |
388 mm |
| Weight (with stand) |
5.5 kg |
| Sustainability |
|---|
| Sustainability certificates |
RoHS |
| Packaging data |
|---|
| Quick start guide |
Yes |
| Cables included |
AC, HDMI, USB, VGA |
| Logistics data |
|---|
| Harmonized System (HS) code |
85285210 |
| Other features |
|---|
| Height (without stand) |
32.2 cm |
| Depth (without stand) |
4.65 cm |
| Width (without stand) |
54 cm |
| Quick start guide |
Yes |
| HDMI |
Yes |
| Energy efficiency scale |
A to G |
| Power supply type |
AC |
| Dimensions (W x D x H) with stand |
540.5 x 128 x 388 mm |
| Placement supported |
Horizontal/Vertical |
| Mean time between failures (MTBF) |
30000 h |
| Display viewable area (HxV) |
527.04 x 296.46 mm |
| Touchscreen type |
Multi-user |
| Touchscreen |
Yes |
| Number of simultaneous touchpoints |
10 |
| Full HD |
Yes |
| Certificates |
|---|
| Certification |
CE, TÜV-Bauart, VCCI-B, EAC, ErP, WEEE, REACH, CB |
