Intel® Smart Response Technology
Intel® Smart Response Technology combines the fast performance of a small solid state drive with the large capacity of a hard disk drive.
Hardware Encryption
Hardware encryption is data encryption done at the drive level. This is used to ensure that the data stored on the drive is secured from unwanted intrusion.
End-to-End Data Protection
End-to-End Data Protection ensures integrity of stored data from the computer to the SSD and back.
Intel® Rapid Start Technology
Intel® Rapid Start Technology allows quick system resumes from the hibernate state.
Features | |
---|---|
Temperature monitoring and logging | No |
Commodity Classification Automated Tracking System (CCATS) | G158436 |
Export Control Classification Number (ECCN) | 5A992C |
SSD ARK ID | 149407 |
Market segment | Mobile |
TBW rating | 200 |
Mean time between failures (MTBF) | 1600000 h |
Uncorrectable Bit Error Rate (UBER) | < 1 per 10^15 bits read |
SSD temperature monitoring | No |
Enhanced Power Loss Data Protection technology | No |
End-to-End Data Protection | Yes |
PCI Express interface data lanes | x4 |
Security algorithms | 256-bit AES |
Hardware encryption | Yes |
Component for | Server/workstation |
NVMe | Yes |
Memory type | 3D2 QLC |
Interface | PCI Express 3.0 |
SSD capacity | 1.02 TB |
SSD form factor | M.2 |
Power | |
---|---|
Power consumption (idle) | 0.04 W |
Power consumption (write) | 0.1 W |
Power consumption (read) | 0.1 W |
Brand-specific features | |
---|---|
Intel® Smart Response Technology | Yes |
Intel High Endurance Technology (HET) | No |
Intel® Rapid Start Technology | Yes |
Intel® Remote Secure Erase | No |
General | |
---|---|
Product Family | Consumer |
Product Series | 660p |
Operational conditions | |
---|---|
Operating / non-operating shock | 1000 G |
Non-operating shock | 1000 G |
Operating shock | 1000 G |
Non-operating vibration | 3.13 G |
Operating vibration | 2.17 G |
Maximum operating temperature | 70 °C |
Operating temperature (T-T) | 0 - 70 °C |
Weight & dimensions | |
---|---|
Weight | 10 g |
Depth | 80 mm |
Width | 22 mm |
Logistics data | |
---|---|
Harmonized System (HS) code | 84717070 |
Other features | |
---|---|
Product codename | Neptune Harbor |
Product series | Intel® SSD 660p Series |
Launch date | Q3'18 |
SSD power consumption (idle) | 0.040W |
Power consumption (active) | 0.1 W |
SSD endurance rating | 200 TBW |
SSD shock | 1000 G |
Sequential reading | 1800 MB/s |
Sequential writing speed | 1800 MB/s |
Status | Launched |
Random write (8GB span) | 220000 IOPS |
Random read (8GB span) | 150000 IOPS |
Internal memory type | PCIe 3.0 x4, NVMe |
Processor family | Intel SSD 660p |
