Lenovo 4XB7A38175 internal solid state drive 2.5" 960 GB SAS V-NAND TLC
Key Features
Storage Capacity: 960GB
Form Factor: 2.5"
Memory Type: V-NAND TLC
Interface: SAS
Hardware Encryption: No Hardware Encryption
NVMe:
Best Suited For: Server/workstation
Overview
The PM1643a Entry SAS 12Gb solid-state drives (SSDs) from Lenovo provide high-performance, reliable storage solutions for high-capacity enterprise applications. Designed for dense storage and with a 12 Gb SAS interface, these drives feature all the capacity and performance that is needed to replace large numbers of 15K rpm and 10K rpm spinning disks, and consolidate storage into tightly packed server configurations. This product guide provides essential presales information to understand the PM1643a Entry SAS 12Gb SSD offerings and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SSDs and consider their use in IT solutions. The ThinkSystem PM1643a Entry SAS 12Gb solid-state drives (SSDs) are next-generation SSDs suitable for a wide range of applications. The PM1643a SAS SSDs are designed for dense storage and with a 12 Gb SAS interface, these drives feature all the capacity and performance that is needed to replace large numbers of 15K rpm and 10K rpm spinning disks, and consolidate storage into tightly packed server configurations.
Hard drive
SSD capacity
960 GB
Memory type
V-NAND TLC
Data transmission
Read speed
1000 MB/s
Write speed
1000 MB/s
Random write (4KB)
40 IOPS
Random read (4KB)
230 IOPS
Write latency
220 µs
Read latency
240 µs
Data transfer rate
12 Gbit/s
Endurance
Uncorrectable Bit Error Rate (UBER)
< 1 per 10^17 bits read
Mean time between failures (MTBF)
2000000 h
Performance
Interface
SAS
Component for
Server/workstation
Hot-swap
Yes
SSD capacity
960 GB
S.M.A.R.T. support
Yes
Read speed
1000 MB/s
Write speed
1000 MB/s
Memory type
V-NAND TLC
Uncorrectable Bit Error Rate (UBER)
< 1 per 10^17 bits read
Random write (4KB)
40 IOPS
Random read (4KB)
230 IOPS
Mean time between failures (MTBF)
2000000 h
Write latency
220 µs
Read latency
240 µs
Data transfer rate
12 Gbit/s
Design
Component for
Server/workstation
SSD form factor
2.5"
Features
Interface
SAS
Component for
Server/workstation
Hot-swap
Yes
SSD capacity
960 GB
S.M.A.R.T. support
Yes
Read speed
1000 MB/s
Write speed
1000 MB/s
Memory type
V-NAND TLC
Uncorrectable Bit Error Rate (UBER)
< 1 per 10^17 bits read
Random write (4KB)
40 IOPS
Random read (4KB)
230 IOPS
Mean time between failures (MTBF)
2000000 h
Write latency
220 µs
Read latency
240 µs
Data transfer rate
12 Gbit/s
SSD form factor
2.5"
Harmonized System (HS) code
84717070
Power
Power consumption (write)
12 W
Power consumption (read)
9 W
Operational conditions
Operating temperature (T-T)
0 - 70 °C
Storage temperature (T-T)
-40 - 85 °C
Operating relative humidity (H-H)
5 - 95%
Technical details
Interface
SAS
Hot-swap
Yes
S.M.A.R.T. support
Yes
Operating temperature (T-T)
0 - 70 °C
Storage temperature (T-T)
-40 - 85 °C
Operating relative humidity (H-H)
5 - 95%
SSD form factor
2.5"
Sustainability certificates
RoHS
Weight & dimensions
Weight
158 g
Logistics data
Harmonized System (HS) code
84717070
Other features
Uncorrectable Bit Error Rate (UBER)
< 1 per 10^17 bits read
