- Second generation of the first 2.5 inch, mainstream capacity, 15mm
z-height, nearline drive for space-constrained data centres
- Choose 6Gb/s SAS for data integrity, scalability and fast data access,
or SATA 6Gb/s for fast, economical Tier-2/nearline performance
- The industry’s most reliable 7,200 RPM drive, designed for 24×7
operation with an MTBF of 1.4M hours and an AFR of 0.62%
- Enterprise-class firmware and best-in-class rotational vibration
tolerance maximise system availability and performance
- Lowest operating power (under 6.4W) and enhanced PowerChoice™
options for additional power savings during slow or idling periods;
Workload Management™ technology helps systems to keep drives cool
- Self-Encrypting Drive (SED) option (AES-256) cuts IT drive retirement
costs while protecting data securely where it lives — on the drive1
- FIPS 140-2 Validated™ drives protect data classed as Sensitive but
- Unclassified and Protected1
Features | |
---|---|
Mean time between failures (MTBF) | 1400000 h |
Bytes per sector | 512 |
Average latency | 4.16 ms |
Read seek time | 8.5 ms |
Write seek time | 9.5 ms |
HDD interface transfer rate | 6 Gbit/s |
Storage drive buffer size | 64 MB |
Type | HDD |
Interface | SAS |
HDD speed | 7200 RPM |
HDD capacity | 1 TB |
HDD size | 2.5" |
Power | |
---|---|
Operating voltage | 5 V |
Power consumption (idle) | 3.85 W |
Power consumption (typical) | 6.4 W |
Operational conditions | |
---|---|
Non-operating shock | 400 G |
Operating shock | 70 G |
Non-operating vibration | 3 G |
Operating vibration | 0.5 G |
Operating temperature (T-T) | 5 - 60 °C |
Weight & dimensions | |
---|---|
Weight | 200 g |
Height | 15 mm |
Depth | 100.5 mm |
Width | 70.1 mm |
Packaging data | |
---|---|
Quantity | 1 |
Logistics data | |
---|---|
Harmonized System (HS) code | 84717050 |
