Processor | |
---|---|
Processor number of cores supported | 10 |
Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium®, Intel® Xeon® |
Processor socket | LGA 1200 (Socket H5) |
Processor manufacturer | Intel |
Memory | |
---|---|
Maximum internal memory | 128 GB |
Supported memory module capacities | 4GB, 8GB, 16GB, 32GB |
Supported memory clock speeds | 2133,2400,2666,2933 MHz |
Non-ECC | Yes |
ECC | Yes |
Memory voltage | 1.2 V |
Memory slots type | DIMM |
Number of memory slots | 4 |
Supported memory types | DDR4-SDRAM |
Storage controllers | |
---|---|
RAID levels | 0, 1, 5, 10 |
RAID support | Yes |
Supported storage drive interfaces | Serial ATA III, SATA III |
Internal I/O | |
---|---|
Number of COM connectors | 2 |
TPM connector | Yes |
ATX Power connector (24-pin) | Yes |
Number of SATA III connectors | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 2 |
USB 2.0 connectors | 6 |
Rear panel I/O ports | |
---|---|
DisplayPorts quantity | 2 |
DVI-D ports quantity | 1 |
VGA (D-Sub) ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
Network | |
---|---|
LAN controller | Intel® I210-AT, Intel® I219-LM |
Ethernet LAN | Yes |
Features | |
---|---|
Audio chip | Realtek ALC888S |
Motherboard chipset | Intel W480 |
Motherboard chipset family | Intel |
Motherboard form factor | micro ATX |
Component for | PC |
Expansion slots | |
---|---|
PCI Express x16 (Gen 3.x) slots | 1 |
BIOS | |
---|---|
System Management BIOS (SMBIOS) version | 3.1 |
ACPI version | 6.1 |
BIOS type | UEFI AMI |
Operational conditions | |
---|---|
Storage relative humidity (H-H) | 5 - 95% |
Operating relative humidity (H-H) | 10 - 85% |
Operating temperature (T-T) | 0 - 60 °C |
Storage temperature (T-T) | -40 - 85 °C |
Logistics data | |
---|---|
Harmonized System (HS) code | 84733020 |
Weight & dimensions | |
---|---|
Depth | 243.8 mm |
Width | 243.8 mm |
Other features | |
---|---|
Number of DIMM slots | 4 |
Number of processors supported | 1 |
PCI Express x4 (Gen 3.x) slots | 2 |
