Super DSL - the Future of the Internet
The Archer VR1210v features Super VDSL (VDSL2 Profile 35b), the latest generation of DSL technology. Downstream is increased by up to 350 Mbps, 3.5× faster than its VDSL2 predecessor.
Lightning-Fast Wired Connections
Four Gigabit ports operate up to 10× faster than Fast Ethernet. Plug your gaming console, desktop, or IPTV in to 4K-ready speeds. The USB 3.0 port allows you to connect hard drives and transfer data up to 10× faster than USB 2.0. Quickly and easily share files, photos, music, and videos across your entire network.
Better Coverage with Beamforming
Beamforming technology dramatically increases coverage by detecting wireless devices and concentrating signal strength towards them. Enjoy stronger, more stable connections—even as mobile devices move from room to room.
MU-MIMO: Efficient Wi-Fi for Every Device
MU-MIMO technology transmits data to multiple devices, simultaneously. No more bandwidth congestion of latency. All devices receive data more quickly as Wi-Fi is used more efficiently.
WAN connection | |
---|---|
WAN connection type | RJ-45 |
3G/4G USB modem compatibility | Yes |
SIM card slot | No |
DSL WAN | Yes |
Ethernet WAN | Yes |
Wireless LAN features | |
---|---|
Channels quantity | 2 channels |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (max) | 867 Mbit/s |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
Network | |
---|---|
VPN support | OpenVPN, PPTP VPN, IPSec VPN |
Media server | Yes |
Built-in FTP server | Yes |
USB sharing | Yes |
Support Samba (storage) | Yes |
Static route | Yes |
Dynamic DNS (DDNS) | Yes |
Port forwarding | Yes |
Port triggering | Yes |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
Cabling technology | 10/100/1000Base-T(X) |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ethernet LAN interface type | Gigabit Ethernet |
Ethernet LAN | Yes |
DSL features | |
---|---|
Internal modem | Yes |
VDSL2 | Yes |
VDSL | Yes |
ADSL2+ | Yes |
ADSL2 | Yes |
ADSL | Yes |
Ports & interfaces | |
---|---|
DC-in jack | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
USB port | Yes |
Ethernet LAN (RJ-45) ports | 4 |
Management features | |
---|---|
MU-MIMO technology | Yes |
WPS push button | Yes |
Reset button | Yes |
Quality of Service (QoS) support | Yes |
Wi-Fi Multimedia (WMM)/(WME) | Yes |
Web-based management | Yes |
Security | |
---|---|
Network address translation (NAT) | Yes |
DMZ support | Yes |
Filtering | Yes |
Stateful Packet Inspection (SPI) | Yes |
Access Control List (ACL) | Yes |
Guest access | Yes |
Firewall security | NAT, SPI |
Firewall | Yes |
Security algorithms | 64-bit WEP, 128-bit WEP, IPSec, WPA, WPA-PSK, WPA2, WPA-PSK2 |
Protocols | |
---|---|
Management protocols | HTTP / HTTPS, SSL |
Routing protocols | RIP-1, RIP-2 |
Switching protocols | IPv4, IPv6 |
Universal Plug and Play (UPnP) | Yes |
DHCP server | Yes |
DHCP client | Yes |
Design | |
---|---|
On/off switch | Yes |
LED indicators | LAN, Link, Power, Status, WAN |
Wall mountable | Yes |
Product colour | Black |
Product type | Portable router |
Sustainability | |
---|---|
Sustainability compliance | Yes |
Sustainability certificates | CE, EAC, RoHS |
Packaging content | |
---|---|
Manual | Yes |
AC adapter included | Yes |
Antenna | |
---|---|
Antenna direction type | Omni-directional |
Antenna gain level (max) | 2 dBi |
Antenna design | Internal |
Features | |
---|---|
Firmware upgradeable | Yes |
Power | |
---|---|
Output current | 1.5 A |
Output voltage | 12 V |
Power source type | AC, DC |
Operational conditions | |
---|---|
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 90% |
System requirements | |
---|---|
Mac operating systems supported | Yes |
Linux operating systems supported | Yes |
Windows operating systems supported | Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
Weight & dimensions | |
---|---|
Width | 214 mm |
Depth | 144.5 mm |
Height | 80 mm |
Packaging data | |
---|---|
Package type | Box |
Technical details | |
---|---|
Compliance certificates | CE, EAC, RoHS |
