TRANSCEND THE LIMITS
ROG Azoth is a 75% gaming keyboard bristling with DIY features traditionally found on premium custom keyboards. A metal top cover with silicone gasket mount and three-layer dampening, hot-swappable, pre-lubed ROG NX mechanical switches and keyboard stabilizer, ROG PBT doubleshot keycaps and bundled switch lube kit combine to create unprecedented typing experiences. ROG Azoth also has an OLED display with intuitive controls, versatile tri-mode connectivity with SpeedNova wireless technology in 2.4 GHz mode, three adjustable tilt positions, and MacOS support.
OLED Display & Three-Way Control Knob
This sophisticated 2-inch OLED panel can set to show keyboard status, including Caps Lock, connection mode and PC/Mac mode indicators. It can also show battery level, multimedia info, custom animations, as well as system parameters such as CPU temperature.
Intuitively make adjustments and tweak settings with the three-way control knob & side button and OLED display.
Versatile Tri-Mode Connection
ROG SpeedNova wireless technology offers up to 2,000+ hours of stable, uninterrupted near-zero-latency gameplay in 2.4 GHz RF mode (RGB and OLED off). Alternatively, you can use Bluetooth mode to connect to up to three devices at the same time, or charge and play simultaneously in wired USB mode.
A Typing Feel Like No Other
Silicone Gaskets
Silicone gasket mount design gives the Azoth a more cushioned and pleasant typing feel than traditional mechanical keyboards.
Silicone Pad
Durable 3.5 mm-thick silicone pad to absorb noise
PORON® Foam
PORON® foam to absorb case ping and hollowness
Silicone Foam
Silicone foam-lined base case completely eliminates echoes and ensures a flat surface for the PORON® foam
ROG NX Mechanical Switch
ROG-exclusive gaming switch -
Tuned for great keystroke feel and consistency with fast actuation.
The switches have lubricated stems and base housings that offer a smoother click feel and eliminate spring bouncing noises respectively.
LINEAR & SWIFT
ROG NX Red Mechanical Switches provide a 1.8mm actuation point for fast input. Initial actuation force of 40gf helps prevent accidental keystrokes, and it extends to 55gf for perfect rebound feedback. As a result, keystrokes are instantaneous and have a smooth and linear feel.
ULTRA TACTILE
ROG NX Brown Mechanical Switches have a 2mm actuation point, as preferred by traditional brown switch users. The tactile force of 58gf combined with a click ratio of 33% gives every keystroke an obvious, more pronounced tactile response.
CLICKY & TACTILE
ROG NX Blue Mechanical Switches feature a 2.3mm actuation point, standard 16% click ratio, and an enthusiast-preferred 65gf tactile force — all to provide firm and superb feedback with each keystroke.
Better Typing Experience
ROG Keyboard Stabilizer
This pre-lubed keyboard stabilizer has been specially tuned with gamers in mind; it produces less friction, allowing long keys such as Spacebar, Shift and Enter to deliver keystrokes that stay true to the original switch feel.
* ROG Azoth is also compatible with costar stabilizers.
ROG PBT Doubleshot Keycaps
ROG PBT doubleshot keycaps provide a unique and premium feel, as well as offer long-lasting durability. Key design has been optimized with mid-height keycaps (similar to Cherry profile keycaps) and a shorter stem to reduce key wobble, and provide a more comfortable user experience.
* Keycap material may vary by region.
Extra Tuning
The Spacebar has extra lubing and modification for enhanced acoustics and feel.
Ergonomic Design
The Azoth includes two pairs of keyboard feet of different heights, giving it three tilt angles to suit your preference.
Hands-On with your Custom Keyboard
Hot-Swappable Switches*
Swap and install your preferred switch type for a unique, customized feel.
*Even though the switches are hot swappable, it is not recommended to swap out switches when the keyboard is on to prevent short circuiting the keyboard.
DIY Switch Lube Kit
The ROG Azoth includes a complete set of tools for DIY switch lubing. The kit includes a switch opener, keycap puller, switch puller, lube station, brush, and bottle of Krytox™ GPL-205-GD0 lubricant.
ON-THE-FLY MACRO RECORDINGS
Record macros on the fly and map them to fully programmable keys.
ONBOARD MEMORY
Save up to six profiles, including up to five custom schemes, and use them anytime, anywhere.
100% ANTI-GHOSTING & N-KEY ROLLOVER
Every keystroke is registered accurately, no matter how many keys are pressed.
MACOS SUPPORT
Easily toggle MacOS mode to remap the keys for use with MacBooks and Macs.
| Keyboard |
| Keyboard key switch |
Mechanical |
| Rollover |
N-key rollover |
| Polling rate |
1000 Hz |
| Bluetooth version |
5.1 |
| Frequency band |
2.4 GHz |
| Recommended usage |
Gaming |
| Keyboard style |
Straight |
| Keyboard form factor |
75% |
| Built-in memory |
Yes |
| Programmable hot keys |
Yes |
| Windows keys |
Yes |
| Pointing device |
No |
| Numeric keypad |
No |
| Connectivity technology |
Wired & Wireless |
| Adjustable keyboard height |
Yes |
| Device interface |
USB + RF Wireless + Bluetooth |
| Multimedia keys |
Yes |
| Keyboard key profile |
Low-profile |
| Keycaps |
Double shot |
| Ports & interfaces |
| Bluetooth version |
5.1 |
| Frequency band |
2.4 GHz |
| Cable length |
2 m |
| Design |
| Adjustable backlight |
Yes |
| Backlight type |
RGB LED |
| Anti-ghosting |
Yes |
| Built-in display |
Yes |
| Product colour |
White |
| Keyboard style |
Straight |
| Ergonomic design |
Yes |
| Backlight |
Yes |
| Backlight colour |
Multicolour |
| Adjustable keyboard height |
Yes |
| Display type |
OLED |
| Technical details |
| Product colour |
White |
| Ergonomic design |
Yes |
| Backlight |
Yes |
| Backlight colour |
Multicolour |
| Built-in memory |
Yes |
| Windows keys |
Yes |
| Numeric keypad |
No |
| Number of products included |
1 pc(s) |
| Connectivity technology |
Wired & Wireless |
| Multimedia keys |
Yes |
| Ergonomics |
| Detachable cable |
Yes |
| Anti-ghosting |
Yes |
| Built-in display |
Yes |
| Cable length |
2 m |
| Features |
| Detachable cable |
Yes |
| Anti-ghosting |
Yes |
| Cable length |
2 m |
| USB connector type |
USB Type-A |
| Hot-swap |
Yes |
| Receiver |
| Wireless receiver interface |
USB Type-A |
| Power |
| Power source type |
Battery, USB |
| Mouse |
| Mouse included |
No |
| System requirements |
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Packaging content |
| Quick start guide |
Yes |
| Wireless receiver interface |
USB Type-A |
| Receiver included |
Yes |
| Cables included |
USB Type-A - USB Type-C |
| Number of products included |
1 pc(s) |
| Warranty card |
Yes |
| Weight & dimensions |
| Keyboard weight |
1.19 kg |
| Keyboard dimensions (WxDxH) |
326 x 136 x 40 mm |
| Packaging data |
| Quick start guide |
Yes |
| Wireless receiver interface |
USB Type-A |
| Receiver included |
Yes |
| Package weight |
1.94 kg |
| Cables included |
USB Type-A - USB Type-C |
| Package width |
369 mm |
| Package type |
Box |
| Package height |
91 mm |
| Package depth |
179.5 mm |
| Number of products included |
1 pc(s) |
| Warranty card |
Yes |
| Other features |
| Pointing device |
No |
| Connectivity technology |
Wired & Wireless |
